High Efficiency Low Loss Transformer
3D Wound Core Transformer adopts triangular symmetrical silicon steel core,features balanced three phase flux,lower no load loss and ultra low noise.Ideal for urban residential,municipal grid,distributed PV,data center and industrial power projects.Middle East EU Southeast Asia market available.
Basic Info.
Our 3D Wound Core Transformer uses high grade grain oriented silicon steel and triangular 3D wound core structure. The three phase core forms a fully closed symmetrical magnetic path without overlapping lamination joints, which effectively reduces magnetizing loss, vibration and running noise.
Typical Applications
· Urban residential communities, hospitals, schools and commercial complexes
· Distributed photovoltaic systems and solar package substations
· Data centers and critical power supply systems
· Industrial plants, cold storage and mining facilities
· Municipal power grid renovation and rural electrification
· Rail transit and public infrastructure power distribution
Performance parameters for reference
| Core Material | High Grade Grain Oriented Silicon Steel |
| Core Structure | Triangular 3D Wound Core |
| Rated Capacity | 30kVA ~ 2500kVA or customized |
| Rated Voltage | 6kv,10kV，11kV , 33kV etc |
| Frequency: | 50Hz / 60Hz |
| Vector Grou | Dyn11 Yyn0 etc |
| Standard | IEC，IEEE |
We strictly adhere to international manufacturing standards to guarantee that every unit delivered to your site meets precise performance thresholds.
International Certifications: Our facility and products operate under ISO9001 Quality Management, ISO14001 Environmental Management, CE, and international IEEE/IEC standards.
100% Factory Routine & Type Testing:
Every unit undergoes rigorous routine testing before dispatch, including Partial Discharge (PD) measurement (≤5pC), Induced Overvoltage Withstand Test, Temperature Rise Testing, and Insulation Resistance verification.
Dispatch & Packaging Integrity:
Enclosures feature heavy-duty anti-corrosion outdoor coatings and oil-level protection locks, anchored inside reinforced shipping frames for ocean transit.
Core Advantages
· Lower no load loss than conventional stacked silicon steel core transformers
· Ultra low operating noise, suitable for densely populated areas
· Perfectly balanced three phase magnetic flux
· Robust mechanical structure, strong anti short circuit capability
· Better total cost of ownership than expensive amorphous core models
· Available in oil immersed and cast resin dry type versions
Why Choose Us
Our 3D Wound Core Transformer features seamless triangular wound silicon steel core for superior energy efficiency.
· 18%~28% lower no load loss than traditional stacked core models
· Symmetrical three phase magnetic flux, less harmonic interference
· Low vibration and ultra quiet operation for densely populated areas
· Robust construction with strong anti short circuit performance
· Oil immersed and dry type optional, comply with IEC 60076
· Customizable parameters and full factory testing before delivery
FAQ
Q1 What is the main difference between 3D Wound Core Transformer and conventional stacked core transformer?
A1 It adopts triangular closed wound core without lamination joints. It has lower no load loss, much quieter operation and balanced three phase magnetic flux, ideal for noise sensitive areas.
Q2 Is 3D Wound Core Transformer available in dry type and oil immersed type?
A2 Yes. Both oil immersed and cast resin dry type versions are available for selection.
Q3 What is the typical application for 3D Wound Core Transformer?
A3 Widely used for urban residential area, hospital school, distributed solar box substation, data center, industrial plant and municipal grid upgrade.
Q4 How about the noise level of 3D Wound Core Transformer?
A4 Its operating noise is obviously lower than traditional stacked core transformer, very suitable for densely populated residential projects.
Q5 Can you customize transformer parameters for our project?
A5 Yes, we support customized rated capacity, voltage ratio, vector group, protection accessories and outdoor structure.
Q6 What international standards can your 3D wound core transformer meet?
A6 Our transformers comply with IEC 60076 and related standards, we can provide test certificates on request.
